SPECIFICATIONS



Material: Aluminum; Spark Plug Material: Titanium Alloy; Surface Treatment: Plastic Painting

Gasoline Engine Type: Single Cylinder Horizontal, Four-stroke, OHV

Recommended Fuel: 92# or Above Gasoline ; Recommended Lubricant: 4-stroke Lubricant Oil; Hypoid Gear Oil: SAE90

Starting Mode: Pull Start

Transmission Mode: Spline Transmission; Cooling System: Forced Air Cooling

Ignition System: Capacitance Discharge Type

Power Output Mode: Vertical Shaft Output

Power:

Reduction Ratio: 22:15

Displacement: 170cc

Exhaust Volume: 173.3ml/5.86oz

Bore*Stroke: 70*45mm/2.75*1.77inch

Theoretical Power: 3.2kw/3600r/min

Recommended Power: 2.4kw/3000r/min

Torque: 9.0N.m/2, 500r/min

Fuel Consumption: 395g/kw.h

Spark Plug Gap: 0.7-0.8mm/0.027-0.03inch

Carburetor Idle Speed: 1900±100r/min

Valve Clearance (Cold Engine): Intake: 0.15±0.02mm; Exhaust: 0.20±0.02mm

Suspension Height: Suspension Point to Propeller 60-70-80cm/23.6-27.56-31.5inch

Oil Tank Capacity: About 1.2L/40.57oz

Applicable Temperature: 80-110℃/176-230℉

Applicable Boat Length: 3-7m/9.8-22.9ft

Flat Water Load-bearing Capacity: 1T/2204lbs

Heavy Current Load-bearing Capacity: 750kg/1653lbs

Max. Speed: 15km/h

Min. Speed: 8km/h

Product Size: 39.5*34.8*115cm/15.55*13.7*45.27inch

Net Weight: 26kg/57.3lbs

Package Included：

1* Outboard Engine

1* Throttle Main Line
